lcd led retail stand alone digital signage
| PANEL | Panel Type | A+ TFT-LCD Panel 43 inch |
| Active Area | 941.2x529.4 mm (W*H) |
| Max Resolution | 1920x1080 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1100:1 |
| Displaying Color | 16.7M 68% (CIE1931) |
| View Angle | 178°(H) / 178°(V) |
| Response Time | ≤5ms |
| S-system | PAL / NTSC / SECAM |
| Backlight | Patented LED module + Constant power components |
| Brightness | 1000 nits - 3000nits Sunlight readable |
| Life Expectance | ≥60000 Hours |
| ENVIRONMENT | Working Temperature | -35℃ to 55℃ |
| Storage Temperature | -45℃ to 60℃ |
| Working Humidity | 5% to 95% |
| Storage Humidity | 5% to 95% |
| FUNCTION | Video Format | MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB |
| Image Format | JPG,BMP,PNG,TIF,ICO,GIF,TGA |
| Audio Format | MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE |
| Log Management | Supportive to terminal log and playlist log |
| Power Mode | Time-setting On or Off | Manual |
| HARDWARE | Material | cold-rolling metal plate + Special outdoor powder paint |
| Protective Glass | AR Laminated and Tempered glass (6-8mm) |
| Heat Dissipation | Industrial Fan-cooling | Industrial Air-conditioner |
| Protective Level | IP55 | IP65 |
| I/O Interface | DP, HDMI, VGA, DVI, RJ-45, WIFI, 4G, USB, SD Card |
| Play Mode | Plug and play, Network(Remote), Touch |
| Speakers | 2*10W Stereo |
| Dimension | To be customized |
| N.W / G.W | To be customized |
| Accessories | Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card |
| Certificates | ISO9001/CCC/CE/FCC/RoHS/IP65 |
| POWER | Voltage | AC 100V - 240V 50Hz - 60Hz |
| Consumption | ≤ 800W (Due to heat-control system) |
| Standby | ≤ 3W |
Quick Details
Place of Origin:Guangdong, China
Brand Name:CWD
Model Number:CWD-HW430BG-F
Type:TFT
Application:Outdoor
Viewing Angle:178(H)/178(V)
Pixel Pitch:0.4902x0.4902 (HxV)
Contrast Ratio:1100:1
Brightness:2000 nits
Response Time:5ms
Input Voltage:100V-240V
Warranty:3 years, 3 Years
After-sales Service Provided:Video technical support, Free spare parts, Online support
Product name:advertising display
Installation:Wall Mounted
Panel brand:LG, Samsung, AUO, BOE, Chimei, Sharp
Material:Metal Case + Toughened Glass Panel
Optional function:Remote control, Touch, Camera, WiFi, 4G etc
Operation System:Android/Windows 7/8/10
Integration:Printer, Scanner, RFID, NFC, Camera, Keyboard etc
Color:Black, White, Red, Green, Charcoal Grey...
Certificate:CE/CCC/FCC/ROHS/ISO9001
